FLEXTRONIC ® JE-H(st)H-BD - 300 V
Application
FLEXTRONIC® JE-H(st)H-BD is used for signal transmission in industri and power plants.
Construction
Conductor
Bare Cu, 0.8 mm diameter
Insulation
Halogen free compound
Conductor color
Coloured rings and ring-group acc. VDE 0815
Screen
Alu laminated tape
Outer sheath
Halogen free, grey RAL 7032
Drainwire
Tinned Cu 0.8 mm
Technical data
Working temperature
| Flexible: | -5° C to +50° C |
| Fixed: | -30° C to +70° C |
Rated voltage
Max. 225 V
Test voltage
| Conductor/conductor: | 500 V |
| Conductor/screen: | 2000 V |
Bend radius
15 x kabeldiameter
Technical comments
Driftskapacitans (max): 120 nF/km
Isolationsmodstand (min): 100 Ohm/km
Loopmodstand: max. 130 Ohm/km
Skærmdæmpning ved 800 MHz: 1,5 db/km
Approvals
IEC 60754-1, IEC 60332-3, DIN VDE 08015, HM 2, VDE 0472 part 804/813/816, CE, RoHS
Bending radius 15 x cable diameter
Environmentally friendly
Fire retardant acc. to IEC 60332-3
For permanent outdoor installation
Halogen free
Low emission of corrosive gases acc. to IEC 60754
Max. working temp. +70° C
Min. working temperature -30° C
Outdoor use
Suited for wall attachment
Withstands moisture
| SKU | EAN | Dimension (mm) | Current Value (A) | Winding | Diameter (mm)* | Weight (kg/km)* | |
|---|---|---|---|---|---|---|---|
| 561008004 | 5704403031740 | 4x2x0,8 | - | D./Cut | 10,5 | 135 | |
